Radium Engineering Crank Case Vent Catch Can Kit For 2015-2022 Ford F-150 EcoBoost Raptor

Fits Vehicle: EcoBoost powered Ford Raptor and 2015-2022 F-150 EcoBoost V6 (4WD and 2WD)

INCLUDES:

-Anodized oil catch can with integrated condenser and dipstick
-Anodized aluminum F150 Raptor specific mounting bracket
-Anodized aluminum -AN adapter fittings and hose ends
-Stainless steel mounting hardware

The catch cans mount using factory holes and integrate perfectly with the surrounding components. These two oil catch cans (PCV side and CCV side) function completely independent of each other and are sold individually or together. They do NOT vent to atmosphere (VTA), thus are emissions and track legal. Closed loop systems remove the oil and sludge from the PCV gasses before it is routed to the engine to be burned. A closed loop system also promotes negative crankcase pressure for optimal performance. Furthermore, closed systems prevent unwanted oil vapors from entering the cabin. The dipsticks built into the catch cans allow easy inspection of accumulated fluid. No cutting, drilling or permanent modification to the vehicle is required.

This kit secures to the firewall with no modifications required. This catch can runs inline with the crankcase vent port. At low loads it experiences atmospheric pressure, but when the engine is at high load (WOT), this line will experience high flow out of the crankcase. This would normally lead to oil and sludge accumulation in the air filter intake pipe. Oil accumulation will occur in the intercooler which lowers the thermal efficiency properties of the heat exchanger and leads to decreased performance.

Brand

Radium Engineering
